Mid Size Wheel Loaders For Sale
Powerful Cummins engine with low fuel consumption and eco-friendly emissions.
High-efficiency ZF transmission and responsive hydraulic system for smooth operation.
Reinforced body and sturdy axles ensure outstanding load capacity and durability.
Ergonomic cab with 360° camera, ROPS/FOPS design for safety and comfort.
Intelligent monitoring system and reasonable layout for easy maintenance.
Versatile performance, compatible with various attachments for multiple working scenarios.
Product Details
The SW940L wheel loader is a high-performance 4-ton-class construction machine engineered for versatile material handling, earthmoving, and construction operations. As an upgraded Stage V/Tier 4 compliant model, it perfectly balances powerful performance, outstanding fuel efficiency, superior operational stability, and intelligent humanized design. With an operating weight of 14.6 tons, a rated payload of 4.2 tons, and a standard bucket capacity ranging from 2.3m³ to 2.7m³, this loader is widely applicable to infrastructure construction, yard material stacking and loading, municipal engineering, agricultural grain transportation, and various medium and short-distance material handling scenarios. It serves as an ideal cost-effective equipment choice for engineering teams, fleet operators, and agricultural and industrial production sites.
1. Premium Powertrain System & Excellent Fuel Economy
At the core of the SW940L’s exceptional performance is its premium powertrain system, assembled with world-renowned branded components to deliver stable and durable power output. The machine is equipped with a reliable Cummins B6.7 diesel engine, which generates a rated power of 129kW (173HP) at 2200rpm. Adopting advanced Stage V and Tier 4 final emission technology, the engine effectively reduces exhaust emissions, meets strict global environmental protection standards, and allows free operation in various regional construction sites with environmental restrictions. Meanwhile, the optimized fuel combustion system significantly cuts comprehensive fuel consumption, realizing high power output with low energy loss. Matched with a high-efficiency ZF electronically controlled transmission, the powertrain features smooth gear shifting, low power transmission loss, and strong torque reserve. It maintains stable power output even under heavy-load and continuous operation conditions, completely avoiding power attenuation and operation stagnation caused by long-hour working, greatly improving continuous construction efficiency.
2. High-efficiency & Sensitive Hydraulic System
The hydraulic system is the key to the SW940L’s efficient and flexible operation. The machine adopts an optimized high-flow and high-pressure hydraulic system with a maximum system pressure of 25MPa and a maximum hydraulic flow of 220L/min. The precise hydraulic power distribution technology enables all working actions including lifting, dumping, and floating down to respond rapidly and synchronously. The full working cycle time is controlled within 10.2 seconds, which is far more efficient than ordinary loaders of the same tonnage. Equipped with a single-handle hydraulic pilot control system, the operation is sensitive, accurate, and labor-saving. New operators can quickly get started without complex training, effectively reducing the threshold of manual operation and avoiding operational errors caused by unskilled manipulation. Whether for frequent loading and unloading or fine material leveling, the machine can complete construction tasks with high precision and high efficiency.
3. Reinforced Structure & Stable Load-bearing Performance
In terms of structural durability and load-bearing stability, the SW940L is built with a high-strength integral welded frame and thickened reinforced boom and hinge structure. The upgraded long-span hinge design greatly enhances the overall torsional resistance and impact resistance of the equipment, effectively resisting structural deformation and metal fatigue caused by long-term heavy-load operation, bumpy road conditions, and frequent start-stop work. The reinforced heavy-duty drive axles and wear-resistant wide-base engineering tires provide excellent ground adhesion and off-road passability. Even on muddy, gravel, and uneven construction sites, the loader maintains stable driving and working status without slipping or tilting. Its breakout force reaches 107kN, with a straight-line tipping load of 10.145 tons and a full-turn tipping load of 8.571 tons, showing outstanding heavy-load operation capability. The maximum dump height of 2765mm and maximum dump reach of 1158mm also meet the loading requirements of most medium and large trucks, realizing high-efficiency loading and transportation coordination.
4. Safe & Humanized Cab Design
The SW940L prioritizes operator safety and driving comfort with a fully upgraded humanized cab design. The enclosed cab has obtained ROPS and FOPS authoritative certifications, which can effectively prevent safety hazards such as rollover impact and falling object impact, fully protecting the operator’s personal safety during complex construction operations. The cab is equipped with a shock-absorbing luxury seat, an intelligent constant-temperature air conditioning system, and an optimized noise reduction structure, controlling the internal working noise below 75dB. It creates a quiet, comfortable, and temperature-stable working environment, avoiding physical fatigue caused by long-hour continuous operation. To solve the blind spot problem of traditional loaders, this model is fitted with a 360° panoramic camera system, realizing full-range visual monitoring with no dead angles. The intuitive field of view greatly reduces the risk of collision and safety accidents. In addition, the intelligent TFT color display dashboard integrates real-time equipment status monitoring, fault self-diagnosis, and data statistics functions. Operators can clearly check engine status, hydraulic pressure, fuel consumption, and running parameters at a glance, mastering the equipment’s working condition in real time.
5. Intelligent Configuration & Low Maintenance Cost
In terms of intelligent configuration and daily maintenance, the SW940L has achieved a comprehensive upgrade to meet the modern fleet management and low-cost operation needs. It supports keyless start and PIN code authority management, which effectively prevents equipment misuse and facilitates standardized fleet personnel management. The machine is equipped with practical intelligent functions including automatic limit control, one-touch material shaking, parallel lifting, tire pressure monitoring, and attachment intelligent identification. These intelligent configurations simplify complex operating steps, improve construction standardization, and further boost overall working efficiency. In terms of maintenance design, the core power and hydraulic components are arranged reasonably with a standardized and open maintenance space. The external air filter and vulnerable parts are convenient for disassembly, replacement, and daily inspection, no need for complex tools and professional operations. It greatly shortens maintenance time, reduces later maintenance difficulty and comprehensive use cost, and improves the equipment’s overall attendance rate.
6. Versatile Application Scenarios
With strong universal adaptability, the SANY SW940L wheel loader supports the replacement of various auxiliary attachments such as grapples, quick-change devices, and fork tines, realizing multi-functional operation of one machine. It can flexibly switch between earthwork excavation, stockyard stacking, garbage handling, farm grain loading and unloading, and garden renovation, perfectly adapting to diverse working scenarios. Featuring high efficiency, low failure rate, low fuel consumption, and wide applicability, the SW940L is a reliable and high-return construction equipment. It not only meets the high-intensity operation needs of commercial engineering projects but also adapts to low-frequency and multi-scenario use of small and medium-sized teams, bringing stable and long-term economic benefits for users.
Operating Weight | 14600kg |
Rated Payload | 4200kg |
Bucket Capacity | 3–2.7m³ |
Engine Model | Cummins B6.7 |
Rated Power/Rotating Speed | 129kW/2200rpm |
Emission Standard | Stage V / Tier 4 Final |
Transmission System | ZF Electronic Control Transmission |
Max Hydraulic System Pressure | 25MPa |
Max Hydraulic Flow | 220L/min |
Total Working Cycle Time | ≤10.2s |
Max Dump Height | 2765mm |
Max Dump Reach: 1158mm | 1158mm |
Breakout Force | 107kN |
Safety Configuration | ROPS/FOPS Cab, 360° Panoramic Camera |
