Loader-sw940
Powerful power, Stage V emission, energy-saving
Reinforced frame, stable and durable for heavy loads
Pilot control, easy, precise and safe operation
Compatible with various attachments for multi-scene use
Easy maintenance, lower upkeep costs
Certified compliant, global after-sales support
Product Details
Powerful and Eco-Friendly Power Assembly System
The SW940 wheel loader adopts a top-tier professional power assembly system, which lays a solid foundation for efficient and stable operation. It is equipped with a turbocharged inline-six diesel engine with a rated power of 129kW, delivering stable and sufficient power output during long-duration continuous operation. Compliant with EU Stage V and EPA Tier 4 Final international emission standards, the equipment effectively reduces harmful exhaust emissions while optimizing fuel combustion efficiency, achieving a perfect balance between environmental protection and energy saving. This advanced emission configuration enables the loader to be fully compliant with the access standards of European, American and other high-end overseas markets, helping users easily pass local environmental inspections and reduce long-term fuel operating costs.
High-Efficiency ZF Transmission System
In terms of transmission system, the SW940 wheel loader is matched with a ZF automatic power-shift transmission, featuring four forward gears and three reverse gears. The professional transmission structure greatly reduces power transmission loss, realizing smooth and stable gear shifting even under full-load heavy-duty operation. The equipment can reach a maximum torque of 1120 N·m at 1500 rpm, providing powerful breakout force for shoveling, digging and pushing materials such as sand, gravel, soil, grain and construction waste. The precisely calibrated power assembly ensures outstanding starting sensitivity, stable acceleration performance and continuous high-efficiency working capacity, fully adapting to high-intensity industrial operation requirements.
Reinforced Structural Design for Heavy Loads
Structural rigidity and load-bearing stability are the core strengths of the SW940 wheel loader. The whole machine has an operating weight of 14.6 tons and a standard rated load of 4.2 tons. Its straight-line static tipping load reaches 10.145 tons, and the full-turn tipping load is 8.571 tons, with a maximum breakout force of 107 kN, enabling it to easily cope with compacted materials and heavy bulk cargo operations. The main frame and lifting arm adopt thickened high-strength alloy steel materials, and all key welding parts are reinforced with professional processes. This optimized rigid structure effectively resists torsion, impact and deformation in harsh working environments, significantly extending the overall service life of the equipment.
Superior Off-Road and Adaptive Performance
In addition, the SW940 loader is equipped with heavy-duty professional drive axles and 20.5R25 large engineering tires, with excellent load-bearing performance and off-road passing capacity. It can operate stably on muddy, uneven, rugged and other complex road surfaces, avoiding slipping and vehicle instability, and ensuring continuous and reliable operation in construction sites, mountainous areas, farmlands and other harsh scenarios.
Precision Hydraulic System Boosts Working Efficiency
The high-precision hydraulic system empowers the SW940 wheel loader with industry-leading working efficiency. The optimized hydraulic system supports a maximum flow of 220 liters per minute and a rated working pressure of 25 MPa, with sensitive and rapid response to operating instructions. The complete working cycle of lifting, dumping and lowering is controlled within 10.2 seconds, realizing high-frequency and high-efficiency cyclic operation. The machine is equipped with a standard 2.3 cubic meter bucket, and an optional enlarged 2.7 cubic meter bucket is available to further improve single-cycle loading capacity and overall operation efficiency.
Flexible Articulated Steering for Narrow Spaces
In terms of operational flexibility, the equipment adopts an advanced ±40° articulated steering design, with a small turning radius and flexible steering response. It can freely shuttle and turn in narrow spaces such as urban construction sites, municipal road sections and farm warehouses, solving the operational pain points of large engineering machinery in limited-space working scenarios and greatly improving the site adaptability of the equipment.
Safe, Quiet and Humanized Cab Design
Adhering to the humanized design concept, the SW940 wheel loader is built with a safe, comfortable and intelligent cab. The cab meets ROPS and FOPS international safety certification standards, which can effectively protect the driver from risks such as vehicle rollover and falling objects during operation. Equipped with high-performance silicone shock absorption devices, the cab greatly reduces vibration transmission during equipment operation. The internal working noise is controlled at 68 decibels, creating a quiet and low-fatigue working environment for long-hour continuous operation.
Intelligent Pilot Control and Full-Range Safety Configuration
In terms of operation control, the SW940 adopts full electric pilot control handles, which are lightweight and labor-saving to operate. It integrates practical functions such as automatic material shaking and parallel lifting, which simplifies operation steps and improves operation accuracy and work quality. The built-in high-definition TFT liquid crystal instrument panel can display real-time data including engine speed, water temperature, oil volume and equipment operating status, facilitating real-time monitoring of equipment conditions by operators. Meanwhile, the 360° panoramic camera system realizes full-range blind-spot monitoring, eliminating visual dead angles and effectively improving driving and operation safety. The high-efficiency constant-temperature air conditioning system further guarantees comfortable working conditions in extreme high and low temperature environments.
Diversified Attachments for Multi-Functional Operation
Versatile multi-scene adaptability is another major highlight of the SW940 wheel loader. The equipment supports rapid replacement of diversified accessories based on actual working needs. In addition to the standard general-purpose bucket, it can be equipped with optional attachments such as log grapples, pallet forks, road sweepers, high-dump buckets and rock buckets. Through quick replacement of accessories, the loader can freely switch between multiple functions including material shoveling and loading, wood grabbing and handling, cargo palletizing and transportation, and road cleaning and snow removal.
Wide Application Across Multiple Industries
The multi-functional integrated design realizes "one machine for multiple purposes", effectively saving users' equipment procurement and site placement costs. Relying on excellent comprehensive performance, the SW940 wheel loader is widely applicable to core scenarios such as construction earthwork operations, agricultural material transportation, municipal environmental sanitation maintenance, port and freight yard cargo handling, and logistics bulk material loading and unloading, covering multiple industries and meeting the differentiated operation needs of various users.
User-Friendly Maintenance for Lower Operating Costs
The SW940 wheel loader is optimized for low-cost operation and convenient daily maintenance, effectively reducing the whole-life cycle use cost for users. All core components and daily maintenance parts are arranged in a centralized and reasonable layout, with large and accessible maintenance openings. Operators can complete daily inspection, oil replacement and routine maintenance work without complex disassembly operations, greatly saving maintenance time and improving equipment attendance rate.
Complete Certifications and Global After-Sales Support
Key vulnerable parts adopt long-life optimized design and universal standard specifications, with convenient market procurement and low replacement cost, effectively reducing later operation and maintenance expenses. In terms of qualification certification, the whole machine has passed authoritative international certifications such as CE and ISO, fully complying with the safety and technical standards of mainstream global markets. Supported by a complete global after-sales service system, users worldwide can obtain timely technical guidance, spare parts supply and professional after-sales maintenance services, ensuring stable and long-term operation of the equipment.
Conclusion: SW940 Loader, A Cost-Effective All-Round Engineering Solution
In conclusion, the SW940 wheel loader integrates robust power output, ultra-sturdy structural design, high-efficiency hydraulic operation, humanized intelligent control, full-scene adaptability and low-lifecycle maintenance costs, achieving comprehensive and balanced breakthroughs in core performance, practical applicability and economic value. As a newly upgraded medium-sized engineering machinery tailored for global complex working conditions, it stands out among peer products with reliable quality and cost-effective performance. It perfectly fits the diverse operation demands of engineering contractors, agricultural enterprises, municipal departments and logistics companies worldwide. With the continuous advancement of global infrastructure construction, agricultural industrialization and urban green municipal development, the SW940 wheel loader will keep delivering stable, efficient and energy-saving equipment solutions for global users, serving as a trustworthy and long-term partner for various material handling and engineering construction operations across industries.
Operating Weight | 14.6 t / 14,600 kg |
Rated Load Capacity | 4.2 t |
Straight Tipping Load | 10.145 t |
Full-turn Tipping Load | 8.571 t |
Maximum Breakout Force | 107 kN |
Standard Bucket Capacity | 2.3 m³ |
Optional Bucket Capacity | 2.7 m³ |
