Loader Tank

Loader tank is a core fluid storage component for loaders, mainly divided into fuel tank and hydraulic tank. It stores diesel fuel or hydraulic oil and fits wheel loaders, skid steer loaders and other models. Custom design is available.

1. Main Types & Functions

Fuel Tank

Function: Provides stable fuel supply for the engine to ensure continuous operation.

Application: Compatible with wheel loaders, skid steer loaders and other construction equipment.

Hydraulic Tank

Function: Stores hydraulic oil, and works for heat dissipation, degassing and impurity sedimentation to keep the hydraulic system running stably.

Common capacity: 60L - 4500L.

2. Materials & Manufacturing Technology

Stainless Steel (304/316): Excellent corrosion resistance and high structural strength, widely used for hydraulic tanks. Service life: 8 - 10 years.

Carbon Steel (Q235): Cost-effective with good weldability. Coated with anti-rust paint, mostly applied to fuel tanks.

HDPE (Rotational Molding): Lightweight, impact-resistant and anti-corrosive, ideal for small-sized tanks with capacity of 20L - 150L.

Processing Technology: Integral forming or welded structure for excellent sealing and zero leakage. Surface treated with sand blasting and anti-corrosion coating (coating thickness: 80 - 120μm).

3. Main Specifications

Fuel Tank

Capacity: Standard 50L - 300L; customized large capacity over 500L is available.

Working pressure: Normal pressure (0.02 - 0.05MPa).

Ports: Fuel inlet, fuel outlet, return port, drain port and connector for liquid level sensor.

Hydraulic Tank

Capacity: Common range 100L - 1000L; up to 1280L for large loaders.

Working pressure: 0.3 - 0.5MPa; pressure test standard: 1.2MPa.

Standard Fittings: Air filter, oil level gauge, drain valve, oil baffle and heat dissipation pipeline.

4. Structural Features

Leak-proof Design: Equipped with flanges and rubber sealing rings. All welds pass non-destructive testing to prevent oil leakage.

Impact & Vibration Resistance: Reinforcing ribs on the tank body adapt to harsh working conditions with frequent vibration and collision.

Heat Dissipation & Oil Purification: Internal baffles separate air bubbles and impurities; external cooling ribs accelerate heat dissipation.

Easy Installation: Custom shapes and reserved bolt holes fit original vehicle frames and modified installation positions perfectly.

Safety Configuration: Lockable tank cap, overflow protection and anti-static design, complying with construction machinery safety regulations.

5. Custom Service (Custom Loader Tank)

Custom dimensions and irregular shapes according to installation space.

Optional materials: stainless steel, carbon steel or HDPE for fuel, hydraulic oil or coolant storage.

Custom position and size of ports to match original pipelines and sensors.

Custom painting colors: engineering yellow, black, grey and other colors for anti-ultraviolet and anti-corrosion performance.

Pre-assembled accessories: oil level gauge, filter, drain valve, sensor, etc. for plug-and-play use.

6. Application & Advantages

Application Scenarios

Construction sites, mines, ports, farms and other heavy-duty working environments.

Product Advantages

Durable: Anti-corrosion and impact-resistant for long service life in tough conditions.

High Efficiency: Reasonable capacity ensures long working hours; optimized hydraulic tank structure improves heat dissipation and oil purification.

Wide Compatibility: Customized products fit most mainstream loader brands and models.

Cost-saving: Low failure rate and less maintenance reduce overall operating costs.

7. Quality Standards & Certifications

Certified with ISO9001 quality management system and CE certification, in line with international construction machinery standards.

Strict factory inspection: Pressure test, leakage test and visual inspection for every product before delivery.
